| 型号 Model | 尺寸 Dimension | ||||
| L | IC | S | d | R | |
| CCMT09T304- JMQ | 9.7 | 9.525 | 3.97 | 4.4 | 0.4 |
| CCMT060204-JHQ | 6.4 | 6.35 | 2.38 | 2.8 | 0.4 |
| CCMT09T304-JHQ | 9.7 | 9.525 | 3.97 | 4.4 | 0.4 |
| CCMT09T308-JHQ | 9.7 | 9.525 | 3.97 | 4.4 | 0.8 |
| CCMT060202-SL1 | 6.4 | 6.35 | 2.38 | 2.8 | 0.2 |
| CCMT060204-SL1 | 6.4 | 6.35 | 2.38 | 2.8 | 0.4 |
| CCMT060208-SL1 | 6.4 | 6.35 | 2.38 | 2.8 | 0.8 |
| CCMT09T302-SL1 | 9.7 | 9.525 | 3.97 | 4.4 | 0.2 |
| CCMT09T304-SL1 | 9.7 | 9.525 | 3.97 | 4.4 | 0.4 |
| CCMT09T308-SLl | 9.7 | 9.525 | 3.97 | 4.4 | 0.8 |
| CCMT120404-SL1 | 12.9 | 12.7 | 4.76 | 5.5 | 0.4 |
| CCMT120408-SL1 | 12.9 | 12.7 | 4.76 | 5.5 | 0.8 |
| CCMT09T302-FML | 9.7 | 12.7 | 3.97 | 4.4 | 0.2 |
| CCMT060208-STR | 6.4 | 6.35 | 2.38 | 2.8 | 0.8 |
| CCMT09T304-STR | 9.7 | 9.7 | 3.97 | 4.4 | 0.4 |
| CCMT09T308-STR | 9.7 | 9.7 | 3.97 | 4.4 | 0.8 |
| CCMT120408-STR | 12.9 | 12.7 | 4.76 | 5.5 | 0.8 |
| CCMT120412-STR | 12.9 | 12.7 | 4.76 | 5.5 | 1.2 |
| CCGT060201-JGQ | 6.4 | 6.35 | 2.38 | 2.8 | 0.1 |
| CCGT060202-JGQ | 6.4 | 6.35 | 2.38 | 2.8 | 0.2 |
| CCGT060204-JGQ | 6.4 | 6.35 | 2.38 | 2.8 | 0.4 |
| CCGT09T301-JGQ | 9.7 | 9.525 | 3.97 | 4.4 | 0.1 |
| CCGT09T302-JGQ | 9.7 | 9.525 | 3.97 | 4.4 | 0.2 |
| CCGT09T304-JGQ | 9.7 | 9.525 | 3.97 | 4.4 | 0.4 |
| CCGT030101L-JF | 3.5 | 3.45 | 1.4 | 1.9 | 0.1 |
| CCGT030101R-JF | 3.5 | 3.45 | 1.4 | 1.9 | 0.1 |
| CCGT030102L-JF | 3.5 | 3.45 | 1.4 | 1.9 | 0.2 |
| CCGT030102R-JF | 3.5 | 3.45 | 1.4 | 1.9 | 0.2 |
| CCGT030104L-JF | 3.5 | 3.45 | 1.4 | 1.9 | 0.4 |
| CCGT030104R-JF | 3.5 | 3.45 | 1.4 | 1.9 | 0.4 |
| CCGT040101L-JF | 4.3 | 4.25 | 1.8 | 2.3 | 0.1 |
| CCGT040101R-JF | 4.3 | 4.25 | 1.8 | 2.3 | 0.1 |
| CCGT040102L-JF | 4.3 | 4.25 | 1.8 | 2.3 | 0.2 |
| CCGT040102R-JF | 4.3 | 4.25 | 1.8 | 2.3 | 0.2 |
| CCGT040104L-JF | 4.3 | 4.25 | 1.8 | 2.3 | 0.4 |
| CCGT040104R-JF | 4.3 | 4.25 | 1.8 | 2.3 | 0.4 |
| CCGT060201L-JU | 6.4 | 6.35 | 2.38 | 2.8 | 0.1 |
| CCGT060201R-JU | 6.4 | 6.35 | 2.38 | 2.8 | 0.1 |
| CCGT060202L-JU | 6.4 | 6.35 | 2.38 | 2.8 | 0.2 |
| CCGT060202R-JU | 6.4 | 6.35 | 2.38 | 2.8 | 0.2 |
| CCGT060204L-JU | 6.4 | 6.35 | 2.38 | 2.8 | 0.4 |
| CCGT060204R-JU | 6.4 | 6.35 | 2.38 | 2.8 | 0.4 |
| CCGT09T301L-JU | 9.7 | 9.525 | 3.97 | 4.4 | 0.1 |
| CCGT09T301R-JU | 9.7 | 9.525 | 3.97 | 4.4 | 0.1 |
| CCGT09T302L-JU | 9.7 | 9.525 | 3.97 | 4.4 | 0.2 |
| CCGT09T302R-JU | 9.7 | 9.525 | 3.97 | 4.4 | 0.2 |
| CCGT09T304L-JU | 9.7 | 9.525 | 3.97 | 4.4 | 0.4 |
| CCGT09T304R-JU | 9.7 | 9.525 | 3.97 | 4.4 | 0.4 |
PRECISION GRADE
Quality
ISO 9001
Turning Insert (Positive) CC
