| 型号 Model | 尺寸 Dimension | |||||
| L | W | G | D | d | t | |
| TGF32R050-005 | 16 | 0.50 | 1.3 | 3/8 | 4.4 | 3.18 |
| TGF32R075-010 | 0.75 | 1.9 | ||||
| TGF32R085-010 | 0.85 | 1.9 | ||||
| TGF32R095-010 | 0.95 | 1.9 | ||||
| TGF32R100-010 | 1.00 | 2.3 | ||||
| TGF32R120-010 | 1.20 | 2.3 | ||||
| TGF32R125-010 | 1.25 | 2.3 | ||||
| TGF32R140-010 | 1.40 | 2.3 | ||||
| TGF32R145-010 | 1.45 | 2.3 | ||||
| TGF32R150-010 | 1.50 | 2.3 | ||||
| TGF32R160-010 | 1.60 | 2.3 | ||||
| TGF32R175-010 | 1.75 | 2.3 | ||||
| TGF32R200-010 | 2.00 | 2.8 | ||||
| TGF32R250-010 | 2.50 | 2.8 | ||||
| TGF32R300-020 | 3.00 | 2.8 | ||||
| TGF32L075-010 | 16 | 0.75 | 1.9 | 3/8 | 4.4 | 3.18 |
| TGF32L090-010 | 0.90 | 1.9 | ||||
| TGF32L095-010 | 0.95 | 1.9 | ||||
| TGF32L100-010 | 1.00 | 2.3 | ||||
| TGF32L120-010 | 1.20 | 2.3 | ||||
| TGF32L125-010 | 1.25 | 2.3 | ||||
| TGF32L140-010 | 1.40 | 2.3 | ||||
| TGF32L145-010 | 1.45 | 2.3 | ||||
| TGF32L150-010 | 1.50 | 2.3 | ||||
| TGF32L175-010 | 1.75 | 2.3 | ||||
| TGF32L200-010 | 2.00 | 2.8 | ||||
| TGF32L250-010 | 2.50 | 2.8 | ||||
| 型号 Model | 尺寸 Dimension | ||||||
| W | Dmax | T | H | d | θ | R | |
| TKF12L050-S | 0.5 | 5 | 3 | 8.7 | 5 | 0° | 0.03 |
| TKF12L070-S | 0.7 | 8 | |||||
| TKF12L100-S | 1.0 | 12 | 0.05 | ||||
| TKF12L125-S | 1.3 | ||||||
| TKF12L150-S | 1.5 | ||||||
| TKF12L200-S | 2.0 | ||||||
| TKF12R050-S | 0.5 | 5 | 3 | 8.7 | 5 | 0° | 0.03 |
| TKF12R070-S | 0.7 | 8 | |||||
| TKF12R100-S | 1.0 | 12 | 0.05 | ||||
| TKF12R125-S | 1.3 | ||||||
| TKF12R150-S | 1.5 | ||||||
| TKF12R200-S | 2.0 | ||||||
| TKF12L050-S-16DR | 0.5 | 5 | 3 | 8.7 | 5 | 0° | 0.03 |
| TKF12L070-S-16DR | 0.7 | 8 | |||||
| TKF12L100-S-16DR | 1.0 | 12 | 0.05 | ||||
| TKF12L125-S-16DR | 1.3 | ||||||
| TKF12L150-S-16DR | 1.5 | ||||||
| TKF12L200-S-16DR | 2.0 | ||||||
| TKF12R050-S-16DR | 0.5 | 5 | 3 | 8.7 | 5 | 0° | 0.03 |
| TKF12R070-S-16DR | 0.7 | 8 | |||||
| TKF12R100-S-16DR | 1.0 | 12 | 0.05 | ||||
| TKF12R125-S-16DR | 1.3 | ||||||
| TKF12R150-S-16DR | 1.5 | ||||||
| TKF12R200-S-16DR | 2.0 | ||||||
| TKF16L150-S | 1.50 | 16 | 4 | 9.5 | 5 | 16° | 0.05 |
| TKF16L200-S | 2.00 | ||||||
| TKF16R150-S | 1.50 | ||||||
| TKF16R200-S | 2.00 | ||||||
| TKF16L150-S-16DL | 1.50 | 16 | 4 | 9.5 | 5 | 16° | 0.05 |
| TKF16L200-S-16DL | 2.00 | ||||||
| TKF16R150-S-16DR | 1.50 | ||||||
| TKF16R200-S-16DR | 2.00 | ||||||
| 型号 Model | 尺寸 Dimension | ||
| CW | R | CDX | |
| PENTA24N050PF005 | 0.50 | 0.05 | 2.50 |
| PENTA24N075PF005 | 0.75 | 0.05 | 2.50 |
| PENTA24N095PF005 | 0.95 | 0.05 | 4.00 |
| PENTA24N0100PF010 | 1.00 | 0.1 | 4.00 |
| PENTA24N0125PF020 | 1.25 | 0.2 | 5.00 |
| PENTA24N0145PF020 | 1.45 | 0.2 | 6.20 |
| PENTA24N0150PF020 | 1.50 | 0.2 | 6.00 |
| PENTA24N0175PF020 | 1.75 | 0.2 | 6.20 |
| PENTA24N0185PF020 | 1.85 | 0.2 | 6.00 |
| PENTA24N0200PF020 | 2.00 | 0.2 | 6.50 |
| PENTA24N0230PF020 | 2.30 | 0.2 | 6.20 |
| PENTA24N0239PF015 | 2.39 | 0.15 | 6.50 |
| PENTA24N0250PF020 | 2.50 | 0.2 | 6.50 |
| PENTA24N0300PF020 | 3.00 | 0.2 | 6.50 |
| PENTA24N0400PF020 | 4.00 | 0.2 | 6.52 |
| PENTA34N150C015 | 1.50 | 0.20 | 8.00 |
| PENTA34N200C020 | 2.00 | 1.00 | 8.00 |
| PENTA34N222C015 | 2.22 | 0.15 | 8.00 |
| PENTA34N230C020 | 2.30 | 0.20 | 8.00 |
| PENTA34N239C015 | 2.39 | 0.15 | 8.00 |
| PENTA34N247C020 | 2.47 | 0.20 | 8.00 |
| PENTA34N250C020 | 2.50 | 0.20 | 8.00 |
| PENTA34N270C010 | 2.70 | 0.10 | 10.00 |
| PENTA34N287C020 | 2.87 | 0.20 | 10.00 |
| PENTA34N300C020 | 3.00 | 0.20 | 10.00 |
| PENTA34N315C015 | 3.15 | 0.15 | 10.00 |
| PENTA34N318C020 | 3.18 | 0.20 | 10.00 |
| PENTA34N330C010 | 3.30 | 0.10 | 10.00 |
| PENTA34N348C020 | 3.48 | 0.20 | 10.00 |
| PENTA34N350C025 | 3.50 | 0.25 | 10.00 |
| PENTA34N398C020 | 3.98 | 0.20 | 10.00 |
| PENTA34N400C030 | 4.00 | 0.30 | 10.00 |
