Upper and Lower Carbide Chamfering Cutter

刃径 Cutting diameter(D) 避空直径 Avoidance diameter(D1) 柄径 Shank diameter(d) 全长 Overall length(L) 有效长 Effective length(L1) L2 L3 Cmax 角度 Angle 3 1.8 3 50 12 11.4 27.0 0.6 60°/90° 4 2.4 4 50 16 15.2 27.5 0.8 60°/90° 5 2.8 5 50 20 18.9 28.0 11 60°/90° 6 3 6 58 24 22.5 33.5 1.5 […]

GRADE

K10-K40

TOLERANCE

±0.001"

Upper and Lower Carbide Chamfering Cutter

Product Overview

刃径 Cutting diameter(D)	避空直径 Avoidance diameter(D1)	柄径 Shank diameter(d)	全长 Overall length(L)	有效长 Effective length(L1)	L2	L3	Cmax	角度 Angle
3	1.8	3	50	12	11.4	27.0	0.6	60°/90°
4	2.4	4	50	16	15.2	27.5	0.8	60°/90°
5	2.8	5	50	20	18.9	28.0	11	60°/90°
6	3	6	58	24	22.5	33.5	1.5	60°/90°
8	4.8	8	64	28	24.6	35.5	1.6	60°/90°
10	6.4	10	73	35	31.2	38.0	1.8	60°/90°
12	7.8	12	84	42	37.6	40.0	2.1	60°/90°
