55 Series Carbide Arch Milling Cutter with Coated

刃径D Cutting diameter 避空长度L1 Avoidance length 柄径d Shank diameter 总长L Overall length 避空径D1 Avoidance diameter R径 R diameter 刃数 Flutes 2 6 4 50 1 R1 2 3 6 4 50 1.5 R1.5 2 4 6 4 50 2 R2 2 5 6 5 50 2.5 R2.5 2 6 10 6 50 3 R3 2 […]

GRADE

K10-K40

TOLERANCE

±0.001"

55 Series Carbide Arch Milling Cutter with Coated

Product Overview

刃径D Cutting diameter	避空长度L1 Avoidance length	柄径d Shank diameter	总长L Overall length	避空径D1 Avoidance diameter	R径 R diameter	刃数 Flutes
2	6	4	50	1	R1	2
3	6	4	50	1.5	R1.5	2
4	6	4	50	2	R2	2
5	6	5	50	2.5	R2.5	2
6	10	6	50	3	R3	2
8	12	8	60	4	R4	2
10	15	10	60	5	R5	2
12	15	12	60	6	R6	2
16	25	16	75	8	R8	2
