55 Series 4 Flutes Deep Groove Corner Radius End Mill

型号 Model 规格 specification(mm) 刃数 Flutes Radius(R) Cutting Dia(D) Flute length(Lc) Shank Dia. (d) Overall length(L) 1*4*4*50 R0.1 1 4 4 50 4 1*6*4*50 R0.1 1 6 4 50 4 1*8*4*50 R0.1 1 8 4 50 4 1*10*4*50 R0.1 1 10 4 50 4 1*12*4*50 R0.1 1 12 4 50 4 1*16*4*50 R0.1 1 16 […]

Coating
tisin
Flutes
4
Helix Angle
35
GRADE
K10-K40
TOLERANCE
±0.001"
55 Series 4 Flutes Deep Groove Corner Radius End Mill

Product Overview

型号 Model 规格 specification(mm) 刃数 Flutes
Radius(R) Cutting Dia(D) Flute length(Lc) Shank Dia. (d) Overall length(L)
1*4*4*50 R0.1 1 4 4 50 4
1*6*4*50 R0.1 1 6 4 50 4
1*8*4*50 R0.1 1 8 4 50 4
1*10*4*50 R0.1 1 10 4 50 4
1*12*4*50 R0.1 1 12 4 50 4
1*16*4*50 R0.1 1 16 4 50 4
1*20*4*50 R0.1 1 20 4 50 4
1*4*4*50 R0.2 1 4 4 50 4
1*6*4*50 R0.2 1 6 4 50 4
1*8*4*50 R0.2 1 8 4 50 4
1*10*4*50 R0.2 1 10 4 50 4
1*12*4*50 R0.2 1 12 4 50 4
1*16*4*50 R0.2 1 16 4 50 4
1*20*4*50 R0.2 1 20 4 50 4
1*4*4*50 R0.2 1 4 4 50 4
1*6*4*50 R0.3 1 6 4 50 4
1*8*4*50 R0.3 1 8 4 50 4
1*10*4*50 R0.3 1 10 4 50 4
1*12*4*50 R0.3 1 12 4 50 4
1*16*4*50 R0.3 1 16 4 50 4
1*20*4*50 R0.3 1 20 4 50 4
1.5*6*4*50 R0.1 1.5 6 4 50 4
1.5*8*4*50 R0.1 1.5 8 4 50 4
1.5*10*4*50 R0.1 1.5 10 4 50 4
1.5*12*4*50 R0.1 1.5 12 4 50 4
1.5*16*4*50 R0.1 1.5 16 4 50 4
1.5*20*4*50 R0.1 1.5 20 4 50 4
1.5*6*4*50 R0.2 1.5 6 4 50 4
1.5*8*4*50 R0.2 1.5 8 4 50 4
1.5*10*4*50 R0.2 1.5 10 4 50 4
1.5*12*4*50 R0.2 1.5 12 4 50 4
1.5*16*4*50 R0.2 1.5 16 4 50 4
1.5*20*4*50 R0.2 1.5 20 4 50 4
1.5*6*4*50 R0.3 1.5 6 4 50 4
1.5*8*4*50 R0.3 1.5 8 4 50 4
1.5*10*4*50 R0.3 1.5 10 4 50 4
1.5*12*4*50 R0.3 1.5 12 4 50 4
1.5*16*4*50 R0.3 1.5 16 4 50 4
1.5*20*4*50 R0.3 1.5 20 4 50 4
2*8*4*50 R0.1 2 8 4 50 4
2*10*4*50 R0.1 2 10 4 50 4
2*12*4*50 R0.1 2 12 4 50 4
2*14*4*50 R0.1 2 14 4 50 4
2*16*4*50 R0.1 2 16 4 50 4
2*20*4*50 R0.1 2 20 4 50 4
2*8*4*50 R0.2 2 8 4 50 4
2*10*4*50 R0.2 2 10 4 50 4
2*12*4*50 R0.2 2 12 4 50 4
2*16*4*50 R0.2 2 16 4 50 4
2*20*4*50 R0.2 2 20 4 50 4
2*8*4*50 R0.3 2 8 4 50 4
2*10*4*50 R0.3 2 10 4 50 4
2*12*4*50 R0.3 2 12 4 50 4
2*16*4*50 R0.3 2 16 4 50 4
2*20*4*50 R0.3 2 20 4 50 4
2*8*4*50 R0.5 2 8 4 50 4
2*10*4*50 R0.5 2 10 4 50 4
2*12*4*50 R0.5 2 12 4 50 4
2*16*4*50 R0.5 2 16 4 50 4
2*20*4*50 R0.5 2 20 4 50 4
3*12*4*50 R0.2 3 12 4 50 4
3*16*4*50 R0.2 3 16 4 50 4
3*20*4*50 R0.2 3 20 4 50 4
3*25*4*60 R0.2 3 25 4 60 4
3*12*4*50 R0.3 3 12 4 50 4
3*16*4*50 R0.3 3 16 4 50 4
3*20*4*50 R0.3 3 20 4 50 4
3*25*4*60 R0.3 3 25 4 60 4
3*12*4*50 R0.5 3 12 4 50 4
3*16*4*50 R0.5 3 16 4 50 4
3*20*4*50 R0.5 3 20 4 50 4
3*25*4*60 R0.5 3 25 4 60 4
3*10*4*50 R1 3 10 4 50 4
3*12*4*50 R1 3 12 4 50 4
3*16*4*50 R1 3 16 4 50 4
3*20*4*50 R1 3 20 4 50 4
3*25*4*60 R1 3 25 4 60 4
