2/4 Flutes R Milling Cutter

型号 Model R径 Rradius 刃径 Cutting diameter(D) 底刃直径 Bottom blade diameter(D1) 柄径 Shank diameter(d) 全长 Overall length(L) 刃数 Flutes R0.5*3*50 R0.5 4 3 4 50 2/4 R0.75*2.5*50 R0.75 4 2.5 4 50 2/4 R1.0*2*50 R1.0 4 2 4 50 2/4 Rl.25*3.5*50 R1.25 6 3.5 6 50 2/4 R1.5*3*50 R1.5 6 3 6 50 2/4 R1.75*2.5*50 […]

Coating

altisin

Flutes

Helix Angle

GRADE

K10-K40

TOLERANCE

±0.001"

Product Overview

型号 Model	R径 Rradius	刃径 Cutting diameter(D)	底刃直径 Bottom blade diameter(D1)	柄径 Shank diameter(d)	全长 Overall length(L)	刃数 Flutes
R0.5350	R0.5	4	3	4	50	2/4
R0.752.550	R0.75	4	2.5	4	50	2/4
R1.0250	R1.0	4	2	4	50	2/4
Rl.253.550	R1.25	6	3.5	6	50	2/4
R1.5350	R1.5	6	3	6	50	2/4
R1.752.550	R1.75	6	2.5	6	50	2/4
R2.0250	R2.0	6	2	6	50	2/4
R2.5360	R2.5	8	3	8	60	2/4
R3.0260	R3.0	8	2	8	60	2/4
R3.5375	R3.5	10	3	10	75	2/4
R4.0275	R4.0	10	2	10	75	2/4
R5.0275	R5.0	12	2	12	75	2/4
R6.0275	R6.0	14	2	14	75	2/4
